Water Meter Brass Ball Valve

Quantity:
  • BW-B61
  • Thread
  • Fixed Ball Valve
  • Water Industrial Usage
  • Ningbo Bestway
  • China
  • Brass
  • Straight Through Type
  • Fixed Ball Valve
  • Dn15*1/2m*3/4f, Dn15*3/4f*3/4m
  • DN15*1/2M*3/4F, DN15*3/4F*3/4M
  • 8481804090

Product Name:  Water Meter Brass Ball Valve/Brass Ball Valve for water meter/ Water meter valve/Brass Lockable Ball Valve/Brass Lockable Water Meter Ball Valve

Description:
Water Meter Brass Ball Valve/Brass Ball Valve for water meter/ Water meter valve/Brass Lockable Ball Valve/Brass Lockable Water Meter Ball Valvewith brass forged body, brass ball, brass stem and brass handle.

Application: House connection and drinking meter networks.

Material: Brass (CZ122, CuZn39Pb3, CW617, CW614 and so on)

Size:
 DN15*1/2M*3/4F, DN15*3/4F*3/4M (Customed are acceptable)



Connection: Thread (MxF, FxF,MxM) & Welding with coupling


Technical Specification:

Working pressure: 1.6Mpa

Tested Pressure: 2.0Mpa

Working medium: Water, oil, gas

Working temperature: -20° C≤ T≤ 150° C

Thread standard: ISO228  (BSP, NPT etc)

Package details: Each valve by poly bag, inner box, Cartons with pallets. (Package as per client's requirements are acceptable)
Water Meter Brass Ball Valve
Water Meter Brass Ball Valve

In order to quote you the best price timely, please kindly provide the following information in your inquiry:

1) Product details: dimensions

2) Order quantity

3) Attached drawings if customized

4) Any special packing, delivering or other requirements

If you are not sure about any specifics of the product you need, please feel free to contact with us and we are more than happy to help.
